RSV 5000

  • Large collection tank of 8 m volumetric capacity which has big filter with 34 m surface area
  • Automatic filter cleaning system allows the unit to operate for longer periods without interruption.
  • Hydraulic container tilting mechanism
  • The unit is easily mountable on a suitable truck or trailer.

Specifications

DIMENSIONS OF KIT

  • Length
    5411 mm
  • Width
    2100 mm
  • Height
    2100 mm
  • Empty Weight
    4500 kgs

AUXILIARY ENGINE

  • Manufacturer
    Ashok Leyland
  • Model
    4 Cylinder Diesel Engine, Water Cooled
  • Horsepower
    101 hp / 75 kw @ 2200 rpm

BLOWER

  • Manufacturer
    Robuschi
  • Type
    3 Lobe Rotary with atm air injection
  • Construction
    Cast Iron
  • Bearings
    2 Sealed Bearings
  • 2 Sealed Bearings
    60 mm Diameter
  • Drive
    5 XPB Section Banded Individual V Belt
  • Air flow (Max)
    3000 m3/h (1765CFM)
  • Vacuum Pressure(Max)
    700 mbar (21" of HG )
  • Pressure relief Valve
    610 mbar (18" of HG)
  • Maximum pump temp
    140 deg C

HOPPER BODY

  • Hopper
    Heavy Gauge Carbon Steel
  • Steel
    5 mm (6 Gauge) for Walls and Floor
  • Construction
    Welded Carbon Steel
  • Volumetric Capacity
    8 Cubic Meters (10.4 Cubic Yards)
  • Useable Capacity
    5 Cubic Meters
  • Dumping Method
    Rear Door Dump
  • Dump Door
    1350 mm Self Locking Hydraulic Fingers
  • Dump Height
    1100 mm

FILTRATION CHAMBER

  • Type
    Bag type - Primary
  • Clean Method
    Reversible Pulse jet
  • Blast
    Orifice High pressure Located in top
  • Function
    Separate Blast Orifice for each bag
  • Filtration Area
    34 sq m
  • Bag Filter - Filtration
    size 3 microns
  • Bag Filter material
    Felt Polyester 550g/sq.m
  • Pump Cooling Filter
    Catridge type, 1 micron
  • Secondary Filter
    Catridge type, 1 micron
  • No. of. Catridge Filters
    3
  • Purging tank capacity
    11 lit
  • Air tank Capacity
    60 lit
  • Air compressor
    230 cc Engine direct driven

HYDRAULIC SYSTEM

  • Drive
    PTO Gear Pump from Aux Engine
  • Pump Type
    Fixed Displacement
  • Reservior
    34 Litres
  • 34 Litres
    10 Micron Spin-on Inline mounted
  • Function
    Hopper tilting & RD lock and close

ELECTRICAL SYSTEM

  • Display Size
    5 inch
  • Warnings
    Indication and Buzzer in Cab
  • Electrical Control Panel
    Body mounted
  • Ignition Switch
    Start / stop - Push button type
  • Filtration Switch
    Auto / manual (Adjustable timing)
  • Battery
    24 Volts, 80 Ah

CONTROLS

  • Shutdown System
    3 Point System (LLOP, HWT, Overspeed)
  • Emergency stop switch

ACCESSORIES

  • Standard Accessories Fluidized Bulk Nozzle
  • Bulk Nozzle
  • 100 dia Hose x 20mts
  • Hose connectors
  • Optional Accessories Extension hose,
  • Special Filters
